GR135 Motor Grader

Mian Specification for the GR135 motor grader Engine Cummins 6BT5.9-C Rated power/speed 100kW/2200rpm Dimension (LxWxH) (mm)8015x2380x3050mm Operating weight (standard)11000kg Module weight on front wheel3300kg Module weight on rear wheel7700kg Tire size 13.00-24TG RP12 Min. ground clearance410mm Distance between front and rear axles 5780mm Distance between middel and rear wheels 11541mm Max. steering angle of front wheels ±49° Max. lean angle of front wheels ±17° Max.oscillation angle of front axles ±15° Frame articulation angle ±27° Min. turning radius using articulation 6.6mm Blade Max. lift above ground 450mm Max. depth of cutting 535mm Max. blade position angle 90° Blade cutting angle 28° 70° Circle reversing rotation 360° Moldboard width x height 3710x610mm Main Components List Engine: China Cummins Gearbox: Hydraulic control system Axle: Xuzhou MERITOR Multi-valve: Italian made Cyloid motor: Eaton, USA Steering motor: Eaton, USA
